Airgas® Model M973 Brass Specialty High Purity Medical Low Flow Two Stage Pressure Regulator With 1/4" FNPT Connection
Please Call for Lead Time - (262-820-1868)
Part Number: M973SKU: Y12M973-AG
Quantity Available: 0
$700.11
Item Details
These two-stage regulators are specifically designed for low-flow, non-corrosive gas applications where precise delivery pressure is critical. They feature a brass piston sensor in the first stage, a stainless steel diaphragm in the second stage and a preset safety relief valve. A sintered brass filter protects internal parts. These two-stage regulators are also ideal for medical diagnostic applications, such as blood gas analysis, where precise pressure control and low flow rates are required. They are available with 973 pin-indexed yoke connection for use with E medical cylinders. Not to be used for human consumption or digestion.Features
- Convoluted Stainless Steel Diaphragms: Provides superior leak integrity without contamination from a non-metallic liner or seal.
- Low Internal Volume: Allows rapid purging and stabilization of gas flow.
- Low-Flow Design: Provides precise pressure and flow control.
- Small Size: Enables fast, easy fit up.
- Not to be used for human consumption or digestion.
Specifications
- Model» M973
- Usage» Specialty High Purity
- Material» Brass
- Regulator Type» Low Flow Regulator
- Inlet Connection» 1/4" FNPT
- Outlet Connection» 1/4" FNPT
- Max Outlet Pressure» 50 psig
- Gauge Diameter» 1 1/2
WARNING
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
