Airgas® Model L244ALB Brass Specialty High Purity Two Stage Mini Regulator With CGA x 1/8" FNPT Connection
Please Call for Lead Time - (262-820-1868)
Part Number: L244ALBSKU: Y12L244ALB-AG
Quantity Available: 0
$589.53
Item Details
These compact, two-stage analytical series and high-purity stainless steel regulators are ideally suited for lecture bottles and other small cylinders. They are equipped with a CGA-180 connection for easy attachment to Airgas® lecture bottles. Other CGA-connections are available upon request, as the regulator is rated for 3,000 psig inlet pressure. This regulator also features a non-lubricated needle valve, designed to regulate outlet flow. Choose a brass model for analytical or non-corrosive service or a stainless steel model for mildly corrosive service. If used in corrosive service, a cross-purge assembly must be used.Features
- Compact Design: Ideal for lecture bottles and small cylinders.
- Sensitive Diaphragm: Provides accurate pressure settings.
- 1 1/2"" Gauges: Permit easy reading.
- Large Adjusting Knob: Provides excellent sensitivity over a wide range of settings.
- Needle Valve: Provides easy control of flow volume.
Specifications
- Model» L244ALB
- Usage» Specialty High Purity
- Material» Brass
- Regulator Type» Two Stage Mini Regulator
- Inlet Connection» CGA x 1/8" FNPT
- Outlet Connection» 1/8" Compression
- Max Outlet Pressure» 25 psig
- Gauge Diameter» 1 1/2
