Airgas® Model N570K Magnesium Alloy Ultra Low Inlet Pressure Regulator
Part Number: N570KSKU: Y11N570K-AG
$438.65
Item Details
These regulators are specifically designed to provide sensitive, accurate, low-pressure control for laboratory applications. They feature an oversized “pancake” body of magnesium alloy with a Buna-N diaphragm. These regulators are typically used in conjunction with other high-pressure regulators or on house-line systems that limit inlet pressure to 250 psig (except on model N570K the inlet pressure limit is 10 psig). Regulators are adjusted easily by removing the knurled nut and turning the screw to alter the tension on the diaphragm. Because these regulators are not typically recommended for direct connection to cylinders, they are provided with a 1/4" FNPT inlet port. Direct cylinder connection is only permissible when using liquefied compressed gases with vapor pressures below 250 psig such as 1,3-butadiene, n-butane, isobutane, isobutylene, propane, and propylene. With these products, a CGA-510 connection must be used. Note: Inlet pressure should never exceed maximum recommended inlet pressure.Features
- Oversized Diaphragm provides sensitive, accurate, low-pressure control.
- Remote Adjustment prevents accidental outlet pressure change.
- Large, 21/2" Gauge permits accurate, easy reading.
- Lightweight Construction permits easy handling and installation.
Specifications
- "
- Maximum Inlet Pressure: 10 psig
- Outlet Pressure Range: 9"" - 13"" (Water Column Pressure)
- Relief Valve Setting: 28 psig
- Inlet Gauge Range: No Gauge
- Delivery Gauge: No Gauge
- Capacity: 290 scfh @ Max Delivery Pressure
- Flow Capacity: Cv = 0.002
- Designed Leak Rate: Bubble-Tight (helium)
- Weight: 3 lbs
- Ports: (4) 1/4"" FNPT
- Ambient Operating Temperature: -40° F to +150° F"
