Airgas® Model 120A510 Brass Acetylene Service Single Stage Pressure Regulator

Part Number: 120A510SKU: Y11120A510-AG
$370.45

Qty: Order In Bulk
Adding this item to your cart will qualify your order for free shipping.

Item Details

Specially designed for acetylene service, these unique, single-stage regulators are engineered to provide precision performance. The regulators feature a 10-micron, sintered stainless steel filter and a PTFE-lined, nylon-reinforced neoprene diaphragm. Because delivery pressure of acetylene should not exceed 15 psig, these regulators are equipped with a special pressure gauge that features a red warning to indicate unsafe delivery pressure. They are also equipped with a reverse-flow check valve to prevent backflow of gas into the regulator on the outlet.

Features

  • Filtered Seat: Provides added gas stream purity and extended service life.
  • 10-micron Filter: Protects internal parts and filters gas stream.
  • Reverse-Flow Check Valve: Prevents the reverse flow of gas into the regulator.
  • Large/Reinforced Diaphragm: Provides excellent performance characteristics.
  • Red Warning Delivery Gauge: Indicates delivery pressure exceeding 15 psig.

Specifications

  • "
  • Acetylene Service
  • Maximum Inlet Pressure: 400 psig
  • Outlet Pressure Range: 0 - 15 psig
  • Capacity: 210 scfh @ Max Del. Pressure
  • Delivery Gauge Range: 0 - 30 psig
  • Flow Capacity: Cv= 0.15
  • Ambient Operating Temperature: -40° F to 165° F
  • Designed Leak Rate: Bubble-Tight (helium)
  • Weight: 3.32 lbs
  • Decay Inlet Characteristic: 0.085/100 psi
  • Redline: @ 15 psi"

WARNING

  • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
